TANK BEADLOCK

In stock
Part Number
kmc-km-tank-beadlock
The KMC KM236 Tank Beadlock wheel is the performance-driven solution for any Jeep, rock crawler or Baja-style trail runner ... Read More

You have not specified your vehicle, therefore we cannot guarantee this product will fit. To guarantee fitment, please select your vehicle.

Total:

These are Custom products, please click the Inquire button to find a retailer near you to discuss

Starting at $503.00

The KMC KM236 Tank Beadlock wheel is the performance-driven solution for any Jeep, rock crawler or Baja-style trail runner that needs the strength of a beadlock construction while complimenting the visual cues of their rig.

  • True beadlock construction with drain holes in beadlock ring

  • Dual Valve stem holes for quicker deflation

  • Available in Anthracite, Candy Red, Matte Bronze and Satin Black finishes

  • 3pc cap with Metal Base and removable KMC Cap logo for easy customization

  • Available sizes: 17x9 -15mm and -38mm

  • Available in 5, 6 and 8 Lug Applications

SHIPPING
KMC Wheels currently only offers shipping within the continental United States. Typical order processing time is between 1 - 3 business days prior to shipment. Once your order has shipped, you will receive an email with tracking information.

If you reside outside of this area we recommend you to order through one of our Dealers. You can find a local dealer here: Dealer Locator.


RETURNS
For products purchased from one of our retail partners, we recommend contacting that specific retailer regarding any issues you may have with your product.

For products purchased through this site, if you need to return, exchange or have questions about your order please contact customer service at 1-831-290-6514 or online. Customer service will be able to answer any questions you have regarding the product return/exchange procedure.

Write Your Own Review
You're reviewing:TANK BEADLOCK
Your Rating
More Information
Select all options to view Wheel Specs
Need to locate an installer? Click here
SPECIFICATIONS MATRIX
Wheel Diameters:
17"
Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
KM23679050438N KM236 TANK BEADLOCK ANTHRACITE 17X9 5X127 3.50 -38mm 71.50 36.00 lbs 2500 2.05 T163H120-5-H30-S4 $503.00
KM23679050415N KM236 TANK BEADLOCK ANTHRACITE 17X9 5X127 4.41 -15mm 71.50 33.60 lbs 2500 2.05 T163H120-5-H30-S4 $503.00
KM23679060438N KM236 TANK BEADLOCK ANTHRACITE 17X9 6X139.7 3.50 -38mm 108.00 34.90 lbs 2500 2.05 T163H145-6-H30-S4 $503.00
KM23679060415N KM236 TANK BEADLOCK ANTHRACITE 17X9 6X139.7 4.41 -15mm 108.00 33.60 lbs 2500 2.05 T163H145-6-H30-S4 $503.00
KM23679087438N KM236 TANK BEADLOCK ANTHRACITE 17X9 8X170 3.50 -38mm 125.10 35.80 lbs 3700 2.05 T163H170-8-H77-S4 $503.00
KM23679050938N KM236 TANK BEADLOCK CANDY RED 17X9 5X127 3.50 -38mm 71.50 36.00 lbs 2500 2.05 T163H120-5-H30-S5 $503.00
KM23679050915N KM236 TANK BEADLOCK CANDY RED 17X9 5X127 4.41 -15mm 71.50 33.60 lbs 2500 2.05 T163H120-5-H30-S5 $503.00
KM23679060915N KM236 TANK BEADLOCK CANDY RED 17X9 6X139.7 4.41 -15mm 108.00 33.60 lbs 2500 2.05 T163H145-6-H30-S5 $503.00
KM23679060938N KM236 TANK BEADLOCK CANDY RED 17X9 6X139.7 3.50 -38mm 108.00 34.90 lbs 2500 2.05 T163H145-6-H30-S5 $503.00
KM23679087938N KM236 TANK BEADLOCK CANDY RED 17X9 8X170 3.50 -38mm 125.10 35.80 lbs 3700 2.05 T163H170-8-H77-S5 $503.00
KM23679050638N KM236 TANK BEADLOCK MATTE BRONZE 17X9 5X127 3.50 -38mm 71.50 36.00 lbs 2500 2.05 T163H120-5-H30-S8 $503.00
KM23679050615N KM236 TANK BEADLOCK MATTE BRONZE 17X9 5X127 4.41 -15mm 71.50 33.60 lbs 2500 2.05 T163H120-5-H30-S8 $503.00
KM23679060638N KM236 TANK BEADLOCK MATTE BRONZE 17X9 6X139.7 3.50 -38mm 108.00 34.90 lbs 2500 2.05 T163H145-6-H30-S8 $503.00
KM23679060615N KM236 TANK BEADLOCK MATTE BRONZE 17X9 6X139.7 4.41 -15mm 108.00 33.60 lbs 2500 2.05 T163H145-6-H30-S8 $503.00
KM23679087638N KM236 TANK BEADLOCK MATTE BRONZE 17X9 8X170 3.50 -38mm 125.10 35.80 lbs 3700 2.05 T163H170-8-H77-S8 $503.00
KM23679050738N KM236 TANK BEADLOCK SATIN BLACK 17X9 5X127 3.50 -38mm 71.50 36.00 lbs 2500 2.05 T163H120-5-H30-S9 $503.00
KM23679050715N KM236 TANK BEADLOCK SATIN BLACK 17X9 5X127 4.41 -15mm 71.50 33.60 lbs 2500 2.05 T163H120-5-H30-S9 $503.00
KM23679060715N KM236 TANK BEADLOCK SATIN BLACK 17X9 6X139.7 4.41 -15mm 108.00 33.60 lbs 2500 2.05 T163H145-6-H30-S9 $503.00
KM23679060738N KM236 TANK BEADLOCK SATIN BLACK 17X9 6X139.7 3.50 -38mm 108.00 34.90 lbs 2500 2.05 T163H145-6-H30-S9 $503.00
KM23679080738N KM236 TANK BEADLOCK SATIN BLACK 17X9 8X165.1 3.50 -38mm 125.10 35.80 lbs 3700 2.05 T163H170-8-H65-S9 $503.00
KM23679087738N KM236 TANK BEADLOCK SATIN BLACK 17X9 8X170 3.50 -38mm 125.10 35.80 lbs 3700 2.05 T163H170-8-H77-S9 $503.00
