RIOT BEADLOCK

Be the first to review this product

RIOT BEADLOCK

Be the first to review this product

Qty

Starting at $479.00

You have not specified your vehicle; therefore, we cannot guarantee this product will fit. Please confirm our limited liability for choosing your own wheel options. To guarantee fitment, please select your vehicle.

Description

Your off-road rampages beg for a wheel that can handle any terrain with uproarious good looks. Pairing distinctly contoured spokes with a deep concave design, the KM237 Riot Beadlock can handle itself in a scuffle and look good while doing so. Maximize your off-road performance with the KM237's true beadlock construction, designed to prevent de-beading and tire slippage while running tires off-road at a low psi.

Modern round-hole true beadlock design
Forged 6061-T6 beadlock ring
KMC Pro Cap V3 with metal ring
Finishes include: Candy Red with Satin Black Ring, Machined, Machined Face with Satin Black Windows and Ring, Satin Black with Machined Ring
Available sizes: 17x9 0, -12, and -38
5 & 6 lug applications

Locate Your Nearest Installer Covered By Wheel Pros Limited Warranty

To the fullest extent recognized by the laws of the state where the wheel was purchased, KMC Wheels issues this limited warranty to define the rights of the purchaser, and limit KMC Wheels liability, with regard to warranty claims.

KMC Wheels warrants that our wheels will be free from structural failure under normal and intended use for as long as the original retail purchaser owns the product. Customers are specifically directed to the KMC Wheels Consumer Information and WTC Aftermarket Wheel Installation Guidelines, supplied with the wheel. Failure to comply with these instructions shall void this warranty.

See full Warranty details.

Specifications Chart

17"

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Lip Size	Cap	MSRP USD
KM237QB17855000	KM237 RIOT BEADLOCK	CANDY RED W/ SATIN BLACK RING	17X8.5	5X127	4.75	0mm	71.50	30.58 lbs	2500	2.44	T163H120-5-H30-S5	$505.00
KM237QB17856300	KM237 RIOT BEADLOCK	CANDY RED W/ SATIN BLACK RING	17X8.5	6X135	4.75	0mm	87.10	30.58 lbs	2500	2.44	T163H140-6-H30-S5	$505.00
KM237QB17856000	KM237 RIOT BEADLOCK	CANDY RED W/ SATIN BLACK RING	17X8.5	6X139.7	4.75	0mm	108.00	29.48 lbs	2500	2.44	T163H145-6-H30-S5	$505.00
KM237QB17905012N	KM237 RIOT BEADLOCK	CANDY RED W/ SATIN BLACK RING	17X9	5X127	4.53	-12mm	71.50	32.89 lbs	2500	2.33	T163H120-5-H30-S5	$510.00
KM237QB17905038N	KM237 RIOT BEADLOCK	CANDY RED W/ SATIN BLACK RING	17X9	5X127	3.50	-38mm	71.50	34.54 lbs	2500	2.33	T163H120-5-H30-S5	$510.00
KM237QB17906012N	KM237 RIOT BEADLOCK	CANDY RED W/ SATIN BLACK RING	17X9	6X139.7	4.53	-12mm	108.00	31.68 lbs	2500	2.33	T163H145-6-H30-S5	$510.00
KM237QB17906038N	KM237 RIOT BEADLOCK	CANDY RED W/ SATIN BLACK RING	17X9	6X139.7	3.50	-38mm	108.00	33.88 lbs	2500	2.33	T163H145-6-H30-S5	$510.00
KM237DX17855000	KM237 RIOT BEADLOCK	MACHINED	17X8.5	5X127	4.75	0mm	71.50	30.58 lbs	2500	2.44	T163H120-5-H30-P1	$479.00
KM237DX17856300	KM237 RIOT BEADLOCK	MACHINED	17X8.5	6X135	4.75	0mm	87.10	30.58 lbs	2500	2.44	T163H140-6-H30-P1	$479.00
KM237DX17856000	KM237 RIOT BEADLOCK	MACHINED	17X8.5	6X139.7	4.75	0mm	108.00	29.48 lbs	2500	2.44	T163H145-6-H30-P1	$479.00
KM237DX17905012N	KM237 RIOT BEADLOCK	MACHINED	17X9	5X127	4.53	-12mm	71.50	32.89 lbs	2500	1.67	T163H120-5-H30-P1	$553.00
KM237DX17905038N	KM237 RIOT BEADLOCK	MACHINED	17X9	5X127	3.50	-38mm	71.50	34.54 lbs	2500	1.67	T163H120-5-H30-P1	$553.00
KM237DX17906038N	KM237 RIOT BEADLOCK	MACHINED	17X9	6X139.7	3.50	-38mm	108.00	33.88 lbs	2500	1.67	T163H145-6-H30-P1	$553.00
KM237DX17906012N	KM237 RIOT BEADLOCK	MACHINED	17X9	6X139.7	4.53	-12mm	108.00	31.68 lbs	2500	1.67	T163H145-6-H30-P1	$553.00
KM237DB17855000	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X8.5	5X127	4.75	0mm	71.50	30.58 lbs	2500	2.44	T163H120-5-H30-P1	$479.00
KM237DB17856300	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X8.5	6X135	4.75	0mm	87.10	30.58 lbs	2500	2.44	T163H140-6-H30-P1	$479.00
KM237DB17856000	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X8.5	6X139.7	4.75	0mm	108.00	29.48 lbs	2500	2.44	T163H145-6-H30-P1	$479.00
KM237DB17905038N	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X9	5X127	3.50	-38mm	71.50	34.54 lbs	2500	2.33	T163H120-5-H30-P1	$502.00
KM237DB17905012N	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X9	5X127	4.53	-12mm	71.50	32.89 lbs	2500	2.33	T163H120-5-H30-P1	$502.00
KM237DB17906312N	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X9	6X135	4.53	-12mm	87.10	32.89 lbs	2500	2.33	T163H140-6-H30-P1	$502.00
KM237DB17906038N	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X9	6X139.7	3.50	-38mm	108.00	33.88 lbs	2500	2.33	T163H145-6-H30-P1	$502.00
KM237DB17906012N	KM237 RIOT BEADLOCK	MACHINED FACE SATIN BLACK WINDOWS & RING	17X9	6X139.7	4.53	-12mm	108.00	31.68 lbs	2500	2.33	T163H145-6-H30-P1	$502.00
KM237MD17855000	KM237 RIOT BEADLOCK	SATIN BLACK W/ MACHINED RING	17X8.5	5X127	4.75	0mm	71.50	30.58 lbs	2500	2.44	T163H120-5-H30-S2	$490.00
KM237MD17856300	KM237 RIOT BEADLOCK	SATIN BLACK W/ MACHINED RING	17X8.5	6X135	4.75	0mm	87.10	30.58 lbs	2500	2.44	T163H140-6-H30-S2	$490.00
KM237MD17856000	KM237 RIOT BEADLOCK	SATIN BLACK W/ MACHINED RING	17X8.5	6X139.7	4.75	0mm	108.00	29.48 lbs	2500	2.44	T163H145-6-H30-S2	$490.00
KM237MD17905038N	KM237 RIOT BEADLOCK	SATIN BLACK W/ MACHINED RING	17X9	5X127	3.50	-38mm	71.50	34.54 lbs	2500	1.67	T163H120-5-H30-S2	$543.00
KM237MD17905012N	KM237 RIOT BEADLOCK	SATIN BLACK W/ MACHINED RING	17X9	5X127	4.53	-12mm	71.50	32.89 lbs	2500	1.67	T163H120-5-H30-S2	$543.00
KM237MD17906038N	KM237 RIOT BEADLOCK	SATIN BLACK W/ MACHINED RING	17X9	6X139.7	3.50	-38mm	108.00	33.88 lbs	2500	1.67	T163H145-6-H30-S2	$543.00
KM237MD17906012N	KM237 RIOT BEADLOCK	SATIN BLACK W/ MACHINED RING	17X9	6X139.7	4.53	-12mm	108.00	31.68 lbs	2500	1.67	T163H145-6-H30-S2	$543.00
