    RIOT BEADLOCK

    In stock
    Only %1 left
    Part Number
    kmc-km-riot-beadlock

    You have not specified your vehicle; therefore, we cannot guarantee this product will fit. To guarantee fitment, please select your vehicle.

    Total:

    Favorite
    Starting at $479.00

    Your off-road rampages beg for a wheel that can handle any terrain with uproarious good looks. Pairing distinctly contoured spokes with a deep concave design, the KM237 Riot Beadlock can handle itself in a scuffle and look good while doing so. Maximize your off-road performance with the KM237's true beadlock construction, designed to prevent de-beading and tire slippage while running tires off-road at a low psi.

    • Modern round-hole true beadlock design
    • Forged 6061-T6 beadlock ring
    • KMC Pro Cap V3 with metal ring
    • Finishes include: Candy Red with Satin Black Ring, Machined, Machined Face with Satin Black Windows and Ring, Satin Black with Machined Ring
    • Available sizes: 17x9 0, -12, and -38
    • 5 & 6 lug applications

    SHIPPING
    KMC Wheels currently only offers shipping within the continental United States. Typical order processing time is between 1 - 3 business days prior to shipment. Once your order has shipped, you will receive an email with tracking information.

    If you reside outside of this area we recommend you to order through one of our Dealers. You can find a local dealer here: Dealer Locator.


    RETURNS
    For products purchased from one of our retail partners, we recommend contacting that specific retailer regarding any issues you may have with your product.

    For products purchased through this site, if you need to return, exchange or have questions about your order please contact customer service at 1-831-290-6514 or online. Customer service will be able to answer any questions you have regarding the product return/exchange procedure.

    Write Your Own Review
    You're reviewing:RIOT BEADLOCK
    Your Rating
    More Information
    Select all options to view Wheel Specs
    Need to locate an installer? Click here
    Loading...
    RIOT BEADLOCK
    SPECIFICATIONS MATRIX
    Wheel Diameters:
    17"
    Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
    KM237QB17855000 KM237 RIOT BEADLOCK CANDY RED W/ SATIN BLACK RING 17X8.5 5X127 4.75 0mm 71.50 30.58 lbs 2500 2.44 T163H120-5-H30-S5 $505.00
    KM237QB17856300 KM237 RIOT BEADLOCK CANDY RED W/ SATIN BLACK RING 17X8.5 6X135 4.75 0mm 87.10 30.58 lbs 2500 2.44 T163H140-6-H30-S5 $505.00
    KM237QB17856000 KM237 RIOT BEADLOCK CANDY RED W/ SATIN BLACK RING 17X8.5 6X139.7 4.75 0mm 108.00 29.48 lbs 2500 2.44 T163H145-6-H30-S5 $505.00
    KM237QB17905012N KM237 RIOT BEADLOCK CANDY RED W/ SATIN BLACK RING 17X9 5X127 4.53 -12mm 71.50 32.89 lbs 2500 2.33 T163H120-5-H30-S5 $510.00
    KM237QB17905038N KM237 RIOT BEADLOCK CANDY RED W/ SATIN BLACK RING 17X9 5X127 3.50 -38mm 71.50 34.54 lbs 2500 2.33 T163H120-5-H30-S5 $510.00
    KM237QB17906038N KM237 RIOT BEADLOCK CANDY RED W/ SATIN BLACK RING 17X9 6X139.7 3.50 -38mm 108.00 33.88 lbs 2500 2.33 T163H145-6-H30-S5 $510.00
    KM237QB17906012N KM237 RIOT BEADLOCK CANDY RED W/ SATIN BLACK RING 17X9 6X139.7 4.53 -12mm 108.00 31.68 lbs 2500 2.33 T163H145-6-H30-S5 $510.00
    KM237DX17855000 KM237 RIOT BEADLOCK MACHINED 17X8.5 5X127 4.75 0mm 71.50 30.58 lbs 2500 2.44 T163H120-5-H30-P1 $479.00
    KM237DX17856300 KM237 RIOT BEADLOCK MACHINED 17X8.5 6X135 4.75 0mm 87.10 30.58 lbs 2500 2.44 T163H140-6-H30-P1 $479.00
    KM237DX17856000 KM237 RIOT BEADLOCK MACHINED 17X8.5 6X139.7 4.75 0mm 108.00 29.48 lbs 2500 2.44 T163H145-6-H30-P1 $479.00
    KM237DX17905012N KM237 RIOT BEADLOCK MACHINED 17X9 5X127 4.53 -12mm 71.50 32.89 lbs 2500 1.67 T163H120-5-H30-P1 $553.00
    KM237DX17905038N KM237 RIOT BEADLOCK MACHINED 17X9 5X127 3.50 -38mm 71.50 34.54 lbs 2500 1.67 T163H120-5-H30-P1 $553.00
    KM237DX17906038N KM237 RIOT BEADLOCK MACHINED 17X9 6X139.7 3.50 -38mm 108.00 33.88 lbs 2500 1.67 T163H145-6-H30-P1 $553.00
    KM237DX17906012N KM237 RIOT BEADLOCK MACHINED 17X9 6X139.7 4.53 -12mm 108.00 31.68 lbs 2500 1.67 T163H145-6-H30-P1 $553.00
    KM237DB17855000 KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X8.5 5X127 4.75 0mm 71.50 30.58 lbs 2500 2.44 T163H120-5-H30-P1 $479.00
    KM237DB17856300 KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X8.5 6X135 4.75 0mm 87.10 30.58 lbs 2500 2.44 T163H140-6-H30-P1 $479.00
    KM237DB17856000 KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X8.5 6X139.7 4.75 0mm 108.00 29.48 lbs 2500 2.44 T163H145-6-H30-P1 $479.00
    KM237DB17905038N KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X9 5X127 3.50 -38mm 71.50 34.54 lbs 2500 2.33 T163H120-5-H30-P1 $502.00
    KM237DB17905012N KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X9 5X127 4.53 -12mm 71.50 32.89 lbs 2500 2.33 T163H120-5-H30-P1 $502.00
    KM237DB17906312N KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X9 6X135 4.53 -12mm 87.10 32.89 lbs 2500 2.33 T163H140-6-H30-P1 $502.00
    KM237DB17906012N KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X9 6X139.7 4.53 -12mm 108.00 31.68 lbs 2500 2.33 T163H145-6-H30-P1 $502.00
    KM237DB17906038N KM237 RIOT BEADLOCK MACHINED FACE SATIN BLACK WINDOWS & RING 17X9 6X139.7 3.50 -38mm 108.00 33.88 lbs 2500 2.33 T163H145-6-H30-P1 $502.00
    KM237MD17855000 KM237 RIOT BEADLOCK SATIN BLACK W/ MACHINED RING 17X8.5 5X127 4.75 0mm 71.50 30.58 lbs 2500 2.44 T163H120-5-H30-S2 $490.00
    KM237MD17856300 KM237 RIOT BEADLOCK SATIN BLACK W/ MACHINED RING 17X8.5 6X135 4.75 0mm 87.10 30.58 lbs 2500 2.44 T163H140-6-H30-S2 $490.00
    KM237MD17856000 KM237 RIOT BEADLOCK SATIN BLACK W/ MACHINED RING 17X8.5 6X139.7 4.75 0mm 108.00 29.48 lbs 2500 2.44 T163H145-6-H30-S2 $490.00
    KM237MD17905012N KM237 RIOT BEADLOCK SATIN BLACK W/ MACHINED RING 17X9 5X127 4.53 -12mm 71.50 32.89 lbs 2500 1.67 T163H120-5-H30-S2 $543.00
    KM237MD17905038N KM237 RIOT BEADLOCK SATIN BLACK W/ MACHINED RING 17X9 5X127 3.50 -38mm 71.50 34.54 lbs 2500 1.67 T163H120-5-H30-S2 $543.00
    KM237MD17906012N KM237 RIOT BEADLOCK SATIN BLACK W/ MACHINED RING 17X9 6X139.7 4.53 -12mm 108.00 31.68 lbs 2500 1.67 T163H145-6-H30-S2 $543.00
    KM237MD17906038N KM237 RIOT BEADLOCK SATIN BLACK W/ MACHINED RING 17X9 6X139.7 3.50 -38mm 108.00 33.88 lbs 2500 1.67 T163H145-6-H30-S2 $543.00
