GRENADE CRAWL BEADLOCK

GRENADE CRAWL BEADLOCK

This product is fitment specific
To see if this product is compatible Select a vehicle
Starting at $507.00
Product Details
Select all options to view Specs
Locate Your Nearest Installer Covered By Wheel Pros Limited Warranty

To the fullest extent recognized by the laws of the state where the wheel was purchased, KMC Wheels issues this limited warranty to define the rights of the purchaser, and limit KMC Wheels liability, with regard to warranty claims.

KMC Wheels warrants that our wheels will be free from structural failure under normal and intended use for as long as the original retail purchaser owns the product. Customers are specifically directed to the KMC Wheels Consumer Information and WTC Aftermarket Wheel Installation Guidelines, supplied with the wheel. Failure to comply with these instructions shall void this warranty.


See full Warranty details.

Fitment Guide Get in touch with our dedicated support staff

Specifications Chart

17"
18"
20"
Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
KM23578550500 KM235 GRENADE CRAWL BEADLOCK MACHINED 17X8.5 5X127 4.75 00mm 71.50 34.26 lbs 2500 2.47 T163H120-5-H30-P1 $507.00
KM23578563500 KM235 GRENADE CRAWL BEADLOCK MACHINED 17X8.5 6X135 4.75 00mm 87.10 34.26 lbs 2500 2.47 T163H140-6-H30-P1 $507.00
KM23578560500 KM235 GRENADE CRAWL BEADLOCK MACHINED 17X8.5 6X139.7 4.75 00mm 108.00 34.26 lbs 2500 2.47 T163H145-6-H30-P1 $507.00
KM23578591500 KM235 GRENADE CRAWL BEADLOCK MACHINED 17X8.5 6X165.1 4.75 00mm 108.00 34.26 lbs 2500 2.47 $507.00
KM23578580500 KM235 GRENADE CRAWL BEADLOCK MACHINED 17X8.5 8X165.1 4.75 00mm 125.10 32.97 lbs 3640 2.47 T163H170-8-H65-P1 $507.00
KM23579050538N KM235 GRENADE CRAWL BEADLOCK MACHINED 17X9 5X127 3.50 -38mm 71.50 34.83 lbs 2500 3.81 T163H120-5-H30-P1 $566.00
KM23579080538N KM235 GRENADE CRAWL BEADLOCK MACHINED 17X9 8X165.1 3.50 -38mm 125.10 33.81 lbs 3640 3.81 T163H170-8-H65-P1 $566.00
KM23578550700 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 17X8.5 5X127 4.75 00mm 71.50 32.60 lbs 2500 2.47 T163H120-5-H30-S2 $507.00
KM23578563700 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 17X8.5 6X135 4.75 00mm 87.10 34.26 lbs 2500 2.47 T163H140-6-H30-S2 $507.00
KM23578560700 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 17X8.5 6X139.7 4.75 00mm 108.00 34.26 lbs 2500 2.47 T163H145-6-H30-S2 $507.00
KM23578591700 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 17X8.5 6X165.1 4.75 00mm 108.00 34.26 lbs 2500 2.47 $507.00
KM23578580700 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 17X8.5 8X165.1 4.75 00mm 125.10 32.97 lbs 3640 2.47 T163H170-8-H65-S2 $507.00
KM23579050738N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 17X9 5X127 3.50 -38mm 71.50 34.83 lbs 2500 3.81 T163H120-5-H30-S2 $566.00
KM23579080738N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 17X9 8X165.1 3.50 -38mm 125.10 33.81 lbs 3640 3.81 T163H170-8-H65-S2 $566.00
Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
KM23589050524N KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 5X127 4.06 -24mm 71.50 39.82 lbs 2500 2.43 T163H120-5-H30-P1 $585.00
KM23589050510 KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 5X127 5.39 10mm 71.50 35.86 lbs 2500 2.43 T163H120-5-H30-P1 $585.00
KM23589063524N KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 6X135 4.06 -24mm 87.10 39.38 lbs 2500 2.43 T163H140-6-H30-P1 $585.00
KM23589063510 KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 6X135 5.39 10mm 87.10 35.75 lbs 2500 2.43 T163H140-6-H30-P1 $585.00
KM23589060510 KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 6X139.7 5.39 10mm 108.00 35.20 lbs 2500 2.43 T163H145-6-H30-P1 $585.00
KM23589060524N KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 6X139.7 4.06 -24mm 108.00 38.72 lbs 2500 2.43 T163H145-6-H30-P1 $585.00
KM23589080524N KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 8X165.1 4.06 -24mm 125.10 40.92 lbs 3640 2.43 T163H170-8-H65-P1 $585.00
KM23589080510 KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 8X165.1 5.39 10mm 125.10 33.66 lbs 3640 2.43 T163H170-8-H65-P1 $585.00
KM23589087524N KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 8X170 4.06 -24mm 125.10 40.92 lbs 3640 2.43 T163H170-8-H77-P1 $585.00
KM23589087510 KM235 GRENADE CRAWL BEADLOCK MACHINED 18X9 8X170 5.39 10mm 125.10 34.10 lbs 3640 2.43 T163H170-8-H77-P1 $585.00
KM23589050710 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 5X127 5.39 10mm 71.50 35.86 lbs 2500 2.43 T163H120-5-H30-S2 $585.00
KM23589050724N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 5X127 4.06 -24mm 71.50 39.82 lbs 2500 2.43 T163H120-5-H30-S2 $585.00
KM23589063710 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 6X135 5.39 10mm 87.10 35.75 lbs 2500 2.43 T163H140-6-H30-S2 $585.00
KM23589063724N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 6X135 4.06 -24mm 87.10 39.38 lbs 2500 2.43 T163H140-6-H30-S2 $585.00
KM23589060710 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 6X139.7 5.39 10mm 108.00 35.20 lbs 2500 2.43 T163H145-6-H30-S2 $585.00
KM23589060724N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 6X139.7 4.06 -24mm 108.00 38.72 lbs 2500 2.43 T163H145-6-H30-S2 $585.00
KM23589080724N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 8X165.1 4.06 -24mm 125.10 40.92 lbs 3640 2.43 T163H170-8-H65-S2 $585.00
KM23589080710 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 8X165.1 5.39 10mm 125.10 33.66 lbs 3640 2.43 T163H170-8-H65-S2 $585.00
KM23589087710 KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 8X170 5.39 10mm 125.10 34.10 lbs 3640 2.43 T163H170-8-H77-S2 $585.00
KM23589087724N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 18X9 8X170 4.06 -24mm 125.10 40.92 lbs 3640 2.43 T163H170-8-H77-S2 $585.00
Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
KM23521050548N KM235 GRENADE CRAWL BEADLOCK MACHINED 20X10 5X127 3.61 -48mm 71.50 43.76 lbs 2500 4.74 T163H120-5-H30-P1 $675.00
KM23521060548N KM235 GRENADE CRAWL BEADLOCK MACHINED 20X10 6X139.7 3.61 -48mm 108.00 43.76 lbs 2500 4.74 T163H145-6-H30-P1 $675.00
KM23521080548N KM235 GRENADE CRAWL BEADLOCK MACHINED 20X10 8X165.1 3.61 -48mm 125.10 44.42 lbs 3640 4.74 T163H170-8-H65-P1 $675.00
KM23521050748N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 20X10 5X127 3.61 -48mm 71.50 43.76 lbs 2500 4.74 T163H120-5-H30-S2 $671.00
KM23521060748N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 20X10 6X139.7 3.61 -48mm 108.00 43.76 lbs 2500 4.74 T163H145-6-H30-S2 $671.00
KM23521080748N KM235 GRENADE CRAWL BEADLOCK SATIN BLACK 20X10 8X165.1 3.61 -48mm 125.10 44.42 lbs 3640 4.74 T163H170-8-H65-S2 $671.00
