E25 BEADLOCK

Be the first to review this product

NEW

E25 BEADLOCK

Be the first to review this product

This product is fitment specific

To see if this product is compatible Select a vehicle

Qty

Starting at $575.00

You have not specified your vehicle; therefore, we cannot guarantee this product will fit. Please confirm our limited liability for choosing your own wheel options. To guarantee fitment, please select your vehicle.

Description

The KMC E25 takes the classic round-hole off-road wheel and gives it a fresh five-spoke twist built for hardcore off-roaders. Alternating window shapes and a deep concave face bring a modern edge to a proven design. The E25 features a true beadlock construction, allowing off-roaders to air down and tackle the roughest terrain while keeping their tire secure with a unique flush-mount beadlock ring. Getting down to business quickly on the trails is a priority, so we created a unique valve stem cutout and painted indicator to provide easy, quick access. Built strictly for off-road use, this wheel is made to handle serious trail abuse. Available in 5-lug, 6-lug, and 8-lug bolt patterns for a variety of builds from Jeeps and ½-ton trucks, all the way up to heavy-duty rigs.

Select all options to view Specs

Locate Your Nearest Installer Covered By Wheel Pros Limited Warranty

To the fullest extent recognized by the laws of the state where the wheel was purchased, KMC Wheels issues this limited warranty to define the rights of the purchaser, and limit KMC Wheels liability, with regard to warranty claims.

KMC Wheels warrants that our wheels will be free from structural failure under normal and intended use for as long as the original retail purchaser owns the product. Customers are specifically directed to the KMC Wheels Consumer Information and WTC Aftermarket Wheel Installation Guidelines, supplied with the wheel. Failure to comply with these instructions shall void this warranty.

See full Warranty details.

Fitment Guide

Specifications Chart

17"

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Cap	MSRP USD
KM241MX17905012N	KM241 E25 BEADLOCK	BLACKOUT	17X9	5X127	4.53	-12mm	71.50	37.84 lbs	2650	KMCAP101MXB5127SX	$575.00
KM241MX17905038N	KM241 E25 BEADLOCK	BLACKOUT	17X9	5X127	3.50	-38mm	71.50	39.60 lbs	2650	KMCAP101MXB5127SX	$575.00
KM241MX17906301	KM241 E25 BEADLOCK	BLACKOUT	17X9	6X135	5.04	1mm	87.10	37.18 lbs	2650	KMCAP101MXB6135SX	$575.00
KM241MX17906001	KM241 E25 BEADLOCK	BLACKOUT	17X9	6X139.7	5.04	1mm	108.00	36.52 lbs	2650	KMCAP101MXB6135SX	$575.00
KM241MX17906012N	KM241 E25 BEADLOCK	BLACKOUT	17X9	6X139.7	4.53	-12mm	108.00	36.96 lbs	2650	KMCAP101MXB6135SX	$575.00
KM241MX17908038N	KM241 E25 BEADLOCK	BLACKOUT	17X9	8X165.1	3.50	-38mm	125.10	41.58 lbs	4000	KMCAP101MXB8165SX	$575.00
KM241DX17905038N	KM241 E25 BEADLOCK	MACHINED	17X9	5X127	3.50	-38mm	71.50	39.60 lbs	2650	KMCAP101PXB5127SX	$575.00
KM241DX17905012N	KM241 E25 BEADLOCK	MACHINED	17X9	5X127	4.53	-12mm	71.50	37.84 lbs	2650	KMCAP101PXB5127SX	$575.00
KM241DX17906301	KM241 E25 BEADLOCK	MACHINED	17X9	6X135	5.04	1mm	87.10	37.18 lbs	2650	KMCAP101PXB6135SX	$575.00
KM241DX17906312N	KM241 E25 BEADLOCK	MACHINED	17X9	6X135	4.53	-12mm	87.10	37.62 lbs	2650	KMCAP101PXB6135SX	$575.00
KM241DX17906001	KM241 E25 BEADLOCK	MACHINED	17X9	6X139.7	5.04	1mm	108.00	36.52 lbs	2650	KMCAP101PXB6135SX	$575.00
KM241DX17906012N	KM241 E25 BEADLOCK	MACHINED	17X9	6X139.7	4.53	-12mm	108.00	36.96 lbs	2650	KMCAP101PXB6135SX	$575.00
KM241DX17908038N	KM241 E25 BEADLOCK	MACHINED	17X9	8X165.1	3.50	-38mm	125.10	41.58 lbs	4000	KMCAP101PXB8165SX	$575.00
