Description

The KMC KM732 Archer is built for those who'd rather be off-grid than on pavement. Its split six-spoke design pushes into the lip, giving it a deep, layered look that hits hard from every angle. Flow Formed construction keeps weight down and strength up, so you get quicker acceleration, better mileage for extended trail runs, and less strain on your drivetrain when you're deep in the rough stuff. Offered in 17x8.5", 6-lug, with 0mm and +25mm offsets, it's made to handle rocky trails, loose climbs, and high-speed stretches. A solid upgrade for the Toyota Tacoma, Chevy Colorado, and Ford Ranger.

Select all options to view Specs

Locate Your Nearest Installer Covered By Wheel Pros Limited Warranty

To the fullest extent recognized by the laws of the state where the wheel was purchased, KMC Wheels issues this limited warranty to define the rights of the purchaser, and limit KMC Wheels liability, with regard to warranty claims.

KMC Wheels warrants that our wheels will be free from structural failure under normal and intended use for as long as the original retail purchaser owns the product. Customers are specifically directed to the KMC Wheels Consumer Information and WTC Aftermarket Wheel Installation Guidelines, supplied with the wheel. Failure to comply with these instructions shall void this warranty.

See full Warranty details.

Fitment Guide

BRS Technology

Learn More

360° Grip ControlBRS (Bead Retention System) is a ring of 360° machined grooves in the wheel’s bead seat that grips the tire at low PSI, letting you air down safely for off-road traction without bolts or bulky beadlocks.

Installer FriendlyMounts clean, holds tight. No extra tools, no bead damage, and no shop frustration. Fully DOT-approved for daily use.

Multi-Terrain PerformanceSnow. Sand. Side hills. BRS keeps your bead locked when tire PSI drops and the trail gets unpredictable.

Smart TractionRun lower pressure for better control without bolts or legality issues.

Specifications Chart

17"

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Cap	MSRP USD
KM732AX17856800	KM732 ARCHER	GLOSS ANTHRACITE	17X8.5	6X139.7	4.75	0mm	106.10	24.64 lbs	2650	KMCAP100MXA0364CX	$334.00
KM732AX17856825	KM732 ARCHER	GLOSS ANTHRACITE	17X8.5	6X139.7	5.73	25mm	106.10	24.20 lbs	2650	KMCAP100MXA0364CX	$334.00
KM732MX17856300	KM732 ARCHER	MATTE BLACK	17X8.5	6X135	4.75	0mm	87.10	24.86 lbs	2650	KMCAP100MXB0364CX	$334.00
KM732MX17856325	KM732 ARCHER	MATTE BLACK	17X8.5	6X135	5.73	25mm	87.10	24.42 lbs	2650	KMCAP100MXB0364CX	$334.00
KM732MX17856800	KM732 ARCHER	MATTE BLACK	17X8.5	6X139.7	4.75	0mm	106.10	24.64 lbs	2650	KMCAP100MXB0364CX	$334.00
KM732MX17856825	KM732 ARCHER	MATTE BLACK	17X8.5	6X139.7	5.73	25mm	106.10	24.20 lbs	2650	KMCAP100MXB0364CX	$334.00
KM732ZX17856800	KM732 ARCHER	MATTE BRONZE	17X8.5	6X139.7	4.75	0mm	106.10	24.64 lbs	2650	KMCAP100MXZ0364CX	$334.00
KM732ZX17856825	KM732 ARCHER	MATTE BRONZE	17X8.5	6X139.7	5.73	25mm	106.10	24.20 lbs	2650	KMCAP100MXZ0364CX	$334.00
